• Air Cleaner, Dry-type standard filter element
• Front Axle, 10,000 lbs. (4536 kg) capacity - Up to 53 degree turn angle
• Rear wheel drive

RACOR FRAME-MOUNTED SPIN-ON TYPE

• with sight bowl
• drain
• and paper element. includes water-in-fuel telltale dash light - includes 150 watt heater. (STD)

BUTTERFLY VALVE TYPE

• - includes NPE

DANA 19060S, 19,000 LBS. (8618 KG) CAPACITY

• -includes 75W-90 synthetic lubricant and National brand oil seals (STD)

CENTER PASSENGER SEAT

• -with folding back rest that includes storage compartment. (Includes lap belt only)

ALLISON 2400 5-SPEED

• -with 0.74 over drive. Torque rating: 545 lb-ft 26
• 000 lbs. (11
• 785 kg) maximum GVWR/GCWR includes transmission oil cooler in radiator and floor mounted "T" handle shifter with park position.

10,000 LBS. (4536 KG) CAPACITY-UP TO 53 DEGREE TURN ANGLE

• (STD)

DRY-TYPE STANDARD FILTER ELEMENT

• (STD)

SINGLE HORIZONTAL EXHAUST SYSTEM

• -passenger side mounted inside frame rail
• aluminized steel (STD)

DUAL

• 50 gallon (189.3L) fuel capacity
• each
• driver side and passenger side Total 100 gallons

AUTOMATIC ENGINE SHUTDOWN WITH ALARM

• -Includes reset feature. Activated by low or high engine oil pressure
• and high coolant temperature (STD)

AM-FM STEREO RADIO/CASSETTE

• -electronically tuned
• digital display
• clock
• seek-scan
• auto reverse with two speakers in instrument panel
• antenna in "A" pillar

MEDIUM DARK GRAY

• (STD)

FRONT TAPERED LEAF 10,000 LBS. (4536 KG) CAPACITY

• (STD)

RAIL, PAINTED SEMI-GLOSS BLACK 8MM - 80,000 PSI (551,600 KPA) YIELD STRENGTH

• (STD)

PREMIUM, HIGHWAY

• (STD)

GM DURAMAX/ISUZU DIESEL ENGINE-DURAMAX DIESEL 7800 7.8L I6/ ISUZU 6HK1-TC 7.8L I6

• 200 hp (149 kw) @ 2200 rpm and 520 lb-ft torque (702 N-m) @ 1450 rpm-Maximum engine speed 2400 rpm
• (STD)

GOODYEAR

• (STD)

OUTSIDE PASSENGER SIDE AND DRIVER SIDE, WEST COAST STAINLESS STEEL HEADS AND BRACKETS, DUAL 7" X 16".

• (STD)

1250-WATT, 110V

• -Includes protected receptacle on driver's side

STABILIZER BAR-SOLID BAR STYLE

• (STD)

GOODYEAR

• (STD)

HYDRAULIC SPLIT BRAKE SYSTEM

• -with 4-channel ABS disc-type Bosch Hydro Max high performance booster
• tandem master cylinder provides independent front and rear circuits
• front and rear disc Meritor calipers: 15 3/8" (391mm) rotor diameter
• 1 1/2" (39.1 mm) rotor thickness with (4) 2 1/2" (64 mm) diameter pistons (STD)

PASSENGER DOOR LOWER GLASS

• -(Includes passenger side power window)

ELECTRONIC ACTIVATION SWITCH, (ELECTRIC HAND THROTTLE), IP MOUNTED-

• PTO price includes cruise control; includes power-take-gear in transmission

TRUCK APPLICATION

• (STD)

SUPPLEMENTAL INFLATABLE RESTRAINTS NOT AVAILABLE

• (STD)

22SI, 100-AMP MAXIMUM

• (STD)

DUAL, 750 CCA, DELPHI HEAVY-DUTY FREEDOM BS 31-750 12V-320-MINUTE RESERVE CAPACITY @ 27 DEGREES C, 750 CCA @ -18 DEGREES C

• (STD)

HIGH-BACK BUCKET, FIXED HEIGHT, MANUAL BACK ANGLE ADJUSTER-AND LUMBAR

• (STD)

212" (538.4 CM)

• -with 181" (459.7 cm) CA

PREMIUM HIGHWAY

• (STD)

• 11R22.5G-12 350 LBS. (5602 KG) CAPACITY
• RACOR FRAME-MOUNTED SPIN-ON TYPE with sight bowl drain and paper element. includes water-in-fuel telltale dash light - includes 150 watt heater. (STD)
• ELECTRONIC EXHAUST RESTRICTOR (AUTOMATIC)
• BUTTERFLY VALVE TYPE - includes NPE
• CALIFORNIA STATE REQUIREMENTS
• DANA 19060S 19 000 LBS. (8618 KG) CAPACITY -includes 75W-90 synthetic lubricant and National brand oil seals (STD)
• CENTER PASSENGER SEAT -with folding back rest that includes storage compartment. (Includes lap belt only)
• CRUISE CONTROL
• AIR CONDITIONING
• ALLISON 2400 5-SPEED -with 0.74 over drive. Torque rating: 545 lb-ft 26 000 lbs. (11 785 kg) maximum GVWR/GCWR includes transmission oil cooler in radiator and floor mounted "T" handle shifter with park position.
• 10 000 LBS. (4536 KG) CAPACITY-UP TO 53 DEGREE TURN ANGLE (STD)
• DRY-TYPE STANDARD FILTER ELEMENT (STD)
• SINGLE HORIZONTAL EXHAUST SYSTEM -passenger side mounted inside frame rail aluminized steel (STD)
• OIL-LUBRICATED "SYNTHETIC" FRONT WHEEL HUBS WITH CLEAR CAPS
• DUAL 50 gallon (189.3L) fuel capacity each driver side and passenger side Total 100 gallons
• 22.5" X 8.25" (58.9 CM X 21 CM) STEEL DISC -ACCURIDE 10-HOLE FLANGE NUT HUB PILOTED
• REAR STABILIZER BAR
• 11R22.5G-23 000 LBS. (10 430 KG) CAPACITY
• AUTOMATIC ENGINE SHUTDOWN WITH ALARM -Includes reset feature. Activated by low or high engine oil pressure and high coolant temperature (STD)
• AM-FM STEREO RADIO/CASSETTE -electronically tuned digital display clock seek-scan auto reverse with two speakers in instrument panel antenna in "A" pillar
• RATES GVWR AT 25 950 LBS. (11 770 KG) CAPACITY
• SPOT MIRRORS OUTSIDE PASSENGER SIDE AND DRIVER SIDE 8" STAINLESS STEEL
• MEDIUM DARK GRAY (STD)
• FRONT TAPERED LEAF 10 000 LBS. (4536 KG) CAPACITY (STD)
• RAIL PAINTED SEMI-GLOSS BLACK 8MM - 80 000 PSI (551 600 KPA) YIELD STRENGTH (STD)
• BOLTED REAR SUSPENSION
• PREMIUM HIGHWAY (STD)
• ELECTRIC SELF CONTAINED 12V
• GM DURAMAX/ISUZU DIESEL ENGINE-DURAMAX DIESEL 7800 7.8L I6/ ISUZU 6HK1-TC 7.8L I6 200 hp (149 kw) @ 2200 rpm and 520 lb-ft torque (702 N-m) @ 1450 rpm-Maximum engine speed 2400 rpm (STD)
• 97 DECIBELS ELECTRICAL
• GOODYEAR (STD)
• OUTSIDE PASSENGER SIDE AND DRIVER SIDE WEST COAST STAINLESS STEEL HEADS AND BRACKETS DUAL 7" X 16". (STD)
• 1250-WATT 110V -Includes protected receptacle on driver's side
• 5.29:1
• STABILIZER BAR-SOLID BAR STYLE (STD)
• 22.5" X 8.25" (58.9 CM X 21 CM) STEEL DISC-ACCURIDE 10-HOLE FLANGE NUT HUB PILOTED
• GOODYEAR (STD)
• HYDRAULIC SPLIT BRAKE SYSTEM -with 4-channel ABS disc-type Bosch Hydro Max high performance booster tandem master cylinder provides independent front and rear circuits front and rear disc Meritor calipers: 15 3/8" (391mm) rotor diameter 1 1/2" (39.1 mm) rotor thickness with (4) 2 1/2" (64 mm) diameter pistons (STD)
• REAR MULTI-LEAF 21 000 LBS. (9525 KG) CAPACITY
• PASSENGER DOOR LOWER GLASS -(Includes passenger side power window)
• HEAVY-DUTY INCREASED COOLING CAPACITY RADIATOR
• ELECTRONIC ACTIVATION SWITCH (ELECTRIC HAND THROTTLE) IP MOUNTED- PTO price includes cruise control; includes power-take-gear in transmission
• TRUCK APPLICATION (STD)
• SINGLE TAPERED LEAF NOT RATED
• SUPPLEMENTAL INFLATABLE RESTRAINTS NOT AVAILABLE (STD)
• 22SI 100-AMP MAXIMUM (STD)
• DUAL 750 CCA DELPHI HEAVY-DUTY FREEDOM BS 31-750 12V-320-MINUTE RESERVE CAPACITY @ 27 DEGREES C 750 CCA @ -18 DEGREES C (STD)
• HIGH-BACK BUCKET FIXED HEIGHT MANUAL BACK ANGLE ADJUSTER-AND LUMBAR (STD)
• 212" (538.4 CM) -with 181" (459.7 cm) CA
• AIR SUSPENSION HIGH-BACK
• DUAL-NOTE ELECTRIC
• PREMIUM HIGHWAY (STD)
• Steel Wheels
• Tires - Front All-Season
• Rear Wheel Drive
• Steel Wheels
• Tires - Rear All-Season
• ABS
• 4-Wheel Disc Brakes
• Daytime Running Lights
• Privacy Glass
• Intermittent Wipers
• Variable Speed Intermittent Wipers
• Running Boards/Side Steps
• A/C
• Adjustable Steering Wheel
• Power Steering
• Floor Mats
• Power Outlet
• Power Outlet
• Bucket Seats
• Driver Adjustable Lumbar
• Bucket Seats
• Passenger Adjustable Lumbar
• AM/FM Stereo
• Vinyl Seats
• ABS
• 4-Wheel Disc Brakes
• Daytime Running Lights

• Vehicle
• Front Frame Rating: - TBD -
• Axle Ratio - Low Rear (:1): 5.29
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 750
• Cold Cranking Amps @ 0° F (Primary): 750
• Cold Cranking Amps @ 0° F (2nd): 750
• Maximum Alternator Capacity (amps): 100
• Maximum Alternator Watts: 1200
• Cooling System
• Total Cooling System Capacity (qts): 32
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 10000
• Gross Axle Wt Rating - Front (lbs): 10000
• Gross Axle Wt Rating - Front (lbs): 12350
• Gross Axle Wt Rating - Front (lbs): 14600
• Gross Axle Wt Rating - Front (lbs): 9000
• Gross Axle Wt Rating - Rear (lbs): 19000
• Gross Axle Wt Rating - Rear (lbs): 21000
• Gross Axle Wt Rating - Rear (lbs): 23000
• Gross Axle Wt Rating - Rear (lbs): 15800
• Curb Weight - Front (lbs): 5871.8
• Curb Weight - Rear (lbs): 2827.2
• Gross Vehicle Weight Rating Cap (lbs): 25950
• Gross Vehicle Weight Rating Cap (lbs): 26000
• Gross Vehicle Weight Rating Cap (lbs): 60000
• Gross Combined Wt Rating (lbs): 26000
• Gross Combined Wt Rating (lbs): 60000
• Suspension
• Suspension Type - Front: Tapered Leaf
• Suspension Type - Rear: Multi-Leaf
• Spring Capacity - Front (lbs): 10000
• Spring Capacity - Rear (lbs): 21000
• Spring Capacity - Rear (lbs): 19000
• Axle Type - Front: I-Beam
• Axle Type - Rear: Single Speed
• Axle Capacity - Front (lbs): 10000
• Axle Capacity - Rear (lbs): 19000
• Axle Capacity - Rear (lbs): 19000
• Axle Ratio (:1) - Rear: 5.29
• Shock Absorber Diameter - Front (mm): 35
• Shock Absorber Diameter - Rear (mm): 35
• Stabilizer Bar Diameter - Front (in): 1.65
• Stabilizer Bar Diameter - Rear (in): 1.73
• Brakes
• Brake Type: PwrHydraulic
• Brake ABS System: 4-Channel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 15 3/8 x 1 1/2
• Front Brake Rotor Diam x Thickness (in): 15 3/8 x 1 1/2
• Rear Brake Rotor Diam x Thickness (in): 15 3/8 x 1 1/2
• Rear Brake Rotor Diam x Thickness (in): 15 3/8 x 1 1/2
• Tires
• Front Tire Order Code: XWL
• Front Tire Order Code: XTQ
• Rear Tire Order Code: YWL
• Rear Tire Order Code: YTQ
• Front Tire Size: 11R22.5G
• Rear Tire Size: 11R22.5G
• Front Tire Capacity (lbs): 12350
• Rear Tire Capacity (lbs): 23000
• Revolutions/Mile @ 45 mph - Front: 501
• Revolutions/Mile @ 45 mph - Rear: 501
• Revolutions/Mile @ 45 mph - Rear: 561
• Number Of Tires Front: 2
• Number Of Tires Rear: 4
• Number Of Tires Spare: 1
• Wheels
• Front Wheel Size (in): 22.5 x 8.25
• Front Wheel Size (in): 22.5 x 7.5
• Rear Wheel Size (in): 22.5 x 8.25
• Front Wheel Offset (mm): 6.62
• Front Wheel Offset (mm): 5.60
• Rear Wheel Offset (mm): 6.62
• Rear Wheel Offset (mm): 5.60
• # of Bolt Holes - Front: 10
• # of Bolt Holes - Front: 8
• # of Bolt Holes - Rear: 10
• # of Bolt Holes - Rear: 8
• # of Bolt Holes - Spare: 8
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Front Wheel Description Cont.: Hub Piloted
• Rear Wheel Description Cont.: Hub Piloted
• Front Bolt Pattern: 10stud/285.75mm
• Front Bolt Pattern: 8stud/275mm
• Rear Bolt Pattern: 10stud/285.75mm
• Steering
• Steering Ratio (:1), On Center: 22.4
• Steering Ratio (:1), At Lock: 22.4
• Turning Diameter - Curb to Curb (ft): 55.5
• Turning Diameter - Wall to Wall (ft): 59.1
• Frame
• Frame Type: C Channel
• Sect Modulus Rails Only (in³): 12.69
• Frame RBM (N/A): 1015000
• Frame Strength (lbs): 80000
• Frame Thickness (in): 0.32
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 50
• Aux Fuel Tank Capacity, Approx (gal): 100
• Fuel Tank Location: LH Step
• Aux Fuel Tank Location: RH Step
• Exterior Dimensions
• Wheelbase (in): 212
• Length, Overall w/o rear bumper (in): 366.4
• Width, Max w/o mirrors (in): 95.8
• Height, Overall (in): 98.2
• Overhang, Front (in): 58.4
• Overhang, Rear w/o bumper (in): 96
• Front Bumper to Back of Cab (in): 89.4
• Cab to Axle (in): 181
• Cab to End of Frame (in): 277
• Frame Width, Rear (in): 3.2
• Body Length Default Value (ft): 0
• Interior Dimensions
• Passenger Capacity: 3
• Passenger Capacity: 2
• Front Head Room (in): 43.0
• Front Leg Room (in): 41.0
• Front Shoulder Room (in): 79.0
• Front Hip Room (in): 74.4
• Summary
• Vehicle Name: Isuzu FVR
• Body Style: Regular Tilt Chassis Cab
• Body Code: RQ2
• Medium Duty Performance
• Driver Ratio: 0.75
• Torque @ Clutch Engage (ft-lbs): 361.4
• Torque Converter: 1.98
• Static Loaded Radius (in): 19.4
• Static Loaded Radius (in): 15.6
• Max Speed For Gradeability: 65
